How to Integrate IdentityServer with Your Angular Application

Step 1: Install the Angular CLI

To install the CLI using npm, open a VS Code terminal/console window. If you are on a Mac or Linux type following command.

PS E:\>npm install -g @angular/cli


It takes some time to download the CLI and Installed the NPM packages.

Step 2: Create workspace and initial application

1. Run the CLI command ng new and provide the name my-app, as show below. As we are implementing Identity Server so I given a name as “identityServer-app”

PS C:\> ng new identityServer-app


2. The ng new command prompts you for information about features to include in the initial app project and here are the answers of each:

PS C:\> ng new identityServer-app
? Would you like to add Angular routing? Yes
? Which stylesheet format would you like to use? SCSS   [ http://sass-lang.com/documentation/file.SASS_REFERENCE.html#syntax ]
CREATE identityServer -app/angular.json (3958 bytes)
CREATE identityServer -app/package.json (1313 bytes)


This will create required folders to Up and Running with our Application and also install all the NPM packages. This will take some time to finish.

Step 3: Install Oidc-client.js

Go to workplace folder (identityServer-app) and type following command on your terminal to install the latest Oidc-client.js

PS C:\identityServer-app> npm install oidc-client –save


you’ll need the latest version of oidc-client, which you can see in package.json

"oidc-client": "^1.10.1"


Step 4: Update the UserManagerSettings

Create constant object called “ClientSettings” as per below code.

export const ClientSettings = {
  authority: "http://localhost:5000",
  client_id: "identityserverapp",
  redirect_uri: "http://localhost:4200/auth-callback",
  post_logout_redirect_uri: "http://localhost:5000/account/login/",
  response_type: "code",
  scope: "openid profile api",
  filterProtocolClaims: true,
  loadUserInfo: true,
  automaticSilentRenew: true,
  silent_redirect_uri: 'http://localhost:4200/silent-refresh'
};


Step 5: Create function to get Client Settings

Below is content of the get client setting function which inherited UserManagerSettings class which is part of the oidc-client

export function getClientSettings(): UserManagerSettings {
  return {
    authority: ClientSettings.authority,
    client_id: ClientSettings.client_id,
    redirect_uri: ClientSettings.redirect_uri,
    post_logout_redirect_uri: ClientSettings.post_logout_redirect_uri,
    response_type: ClientSettings.response_type,
    scope: ClientSettings.scope,
    filterProtocolClaims: ClientSettings.filterProtocolClaims,
    loadUserInfo: ClientSettings.loadUserInfo,
    automaticSilentRenew: ClientSettings.automaticSilentRenew,
    silent_redirect_uri:ClientSettings.silent_redirect_uri
  };
}


Step 6: Create auth.service file

Create auth.service file and below is content of the auth.service.ts file.

import { HttpClient } from "@angular/common/http";
import { Injectable } from "@angular/core";
import { User, UserManager, UserManagerSettings } from "oidc-client";
import { BehaviorSubject } from "rxjs";

@Injectable({
  providedIn: "root"
})
export class AuthService  {
  private _authNavStatusSource = new BehaviorSubject(false);
  authNavStatus$ = this._authNavStatusSource.asObservable();

  private manager = new UserManager(getClientSettings());
  private user: User | null;

  constructor(private http: HttpClient, private configService: ConfigService) {
    super();

    this.manager.getUser().then(user => {
      this.user = user;
      this._authNavStatusSource.next(this.isAuthenticated());
    });
  }

  login() {
    return this.manager.signinRedirect();
  }

  async completeAuthentication() {
    this.user = await this.manager.signinRedirectCallback();
    this._authNavStatusSource.next(this.isAuthenticated());
  }
  signinSilentCallback(){
    this.manager.signinSilentCallback()
    .catch((err) => {
      console.log(err);
  });
  }

  isAuthenticated(): boolean {
    return (this.user != null && !this.user.expired);
  }

  get authorizationHeaderValue(): string {
    return `${this.user.token_type} ${this.user.access_token}`;
  }

  get name(): string {
    if (this.user !== null && this.user.profile !== undefined){
      return  this.user.profile.name;
    } else {
      return "";
    }
  }

  async signout() {
    await this.manager.signoutRedirect();
  }
}


Step 7: Create authgard service

Create authgard service which help to automatically redirect to logged in page if user is not authenticate.

import { Injectable } from '@angular/core';
import { ActivatedRouteSnapshot, CanActivate, Router, RouterStateSnapshot } from '@angular/router';
import { AuthService } from './auth.service';

@Injectable()
export class AuthGuard implements CanActivate {

  constructor(private router: Router, private authService: AuthService) {

  }

  canActivate(route: ActivatedRouteSnapshot, state: RouterStateSnapshot): boolean {
    if (this.authService.isAuthenticated()) { return true; }
    this.authService.login();
    return false;

  }


Step 8: Create AuthCall back component

Create auth call back component which will be redirect url of after successfully logged in to identity server. Below is content of the auth-callback.ts component

import { Component, OnInit } from "@angular/core";
import { Router } from "@angular/router";
import { AuthService } from "../core/authentication/auth.service";

@Component({
  selector: "app-auth-callback",
  templateUrl: "./auth-callback.component.html",
  styleUrls: ["./auth-callback.component.scss"]
})
export class AuthCallbackComponent implements OnInit {
  error: boolean;

  constructor(
    private authService: AuthService,
    private router: Router
  ) { }

  async ngOnInit() {
    await this.authService.completeAuthentication();
    this.router.navigate(["/home"]);
  }
}


Step 9: Create Home Component

Create Home component which will display after successfully logged in. It is simple component and its routing configuration set to canActive so if user directly use the home link and not authorize then redirect to login page.

Step 10: Create Logout component

Create logout component which we will use when user logout from angular App and we need to redirect to identity server logout screen. Below is code for logout component

import { Component, OnInit } from '@angular/core';
import { AuthService } from '../core/authentication/auth.service';

@Component({
  selector: 'app-logout',
  templateUrl: './logout.component.html',
  styleUrls: ['./logout.component.sass']
})
export class LogoutComponent implements OnInit {

  constructor(private authService: AuthService) {
    this.authService.signout();
  }

  ngOnInit() {
  }
}
